1,000 x 4 @ 1 ohm RMS
590 x 4 @ 2 ohms RMS
350 x 4 @ 4 ohms RMS
4-channel full-range amplifier
Variable 12dB low pass filter: 50Hz – 6kHz
Variable 12dB high pass filter: 15Hz – 6kHz
Variable 12dB Bass Boost @ 50Hz
Power, protection & clipping indicators included
Thermal, voltage, speaker short, and dc-offset protection circuitry
Optional wired remote control with clipping indicator
Introducing the Sundown Full Bridge line of amplifiers! The “Brazilian Style” SFB packs a powerful punch in a compact size, stable down to 1 ohm per channel. Use the SFB to wire several speakers together on every channel – an ideal amp for a PA mid/high speaker array, a large marine system, or your favorite set of separates. If you are looking for raw power on a budget – look no further!
Specifications
Frequency Response: 10HZ-20KHZ(-3dB)
Input Impedance: 56k ohms
Input Sensitivity 5V Max
S/N Ratio 100dB
Minimum Supply Voltage: 9VDC
Maximum Supply Voltage: 16VDC
Working Voltage 10.5v-15.5v
Recommended Fuse Rating 350A
Dimensions 8.86″ x 10.43″ x 2.70″
