SAE Series, Version 4, 200 x 4, 4CH Amplifier

600 x 2 @ 4 ohms RMS (Bridged)
300 x 4 @ 2 ohm RMS
200 x 4 @ 4 ohms RMS
Hi-fidelity Class A/B design
Variable 12dB low & high pass filters: 40Hz-5kHz
Power and protection indicators included
Thermal, voltage, speaker short, and dc-offset protection circuitry
Optional wired remote control with clipping indicator

The SAEv4 is engineered with high-fidelity Class A/B multi-channel architecture, providing an ideal balance between performance and affordability. Leveraging the latest half-bridge technology, these amplifiers deliver clean, powerful audio signals in a compact form factor.

Featuring an all-new chassis and heatsink design with 33% more aluminum, this SAEv4 keeps your system cool even during intense listening sessions. The amp is packed with a variable subsonic, high pass and low pass filters, plus a 4-way protection circuit (thermal, voltage, speaker short, and DC offset). The variable crossover slope (LPF/HPF) and a high signal-to-noise ratio of 92dB further enhance audio quality, with an exceptionally low noise floor.

Whether you create a powerful three-channel system, a dual mono monster, or a four channel system full of fidelity, this amp is ready, willing, and more than able to drive your car audio system with a new level of precision and clarity.

Product Manual

Specifications
Input Sensitivity 6V Max
Signal / Noise Ratio : 92DB
Operation Voltage : DC 10.5V – 15.5V Power Input
Dimensions : 19.29” L x 6.3” W x 2.75” H
